SS Needle Tube Manufacturer, SS Hypodermic Needle Tube, Stainless Steel 316L Needle Tube, 316 Stainless Steel Needle Tube Manufacturer in India
Tubetec Piping Solutions is a remarkable Stainless Steel Needle Tubes Manufacturer in India. 316L Stainless Steel and Hypodermic Needle Tubes, specific to SS Needle Tubes, are made with high quality stainless steel that ensures the SS Needle Tube stand up to corrosion and are long lasting. Made from stainless steel materials, cut to fine tolerances, they provide dependable media conveying and contouring and are suitable for medical equipment and hypodermic needles as well as laboratory applications since they afford the most favorable strength and security in influential areas.
SS Needle Tubes is to provide reliable solution for manufacturing medical and pharmaceutical devices. Designed for precision and performance, these SS Needle Tube aim to deliver excellent strength, corrosion resistance, and consistent functionality in critical applications, ensuring safety and efficiency in medical procedures and laboratory environments.
Stainless Steeel Needle Tube Specification
| Outside Diameter (ODs) | 0.008 to 0.203 in. (0.2 to 5.2 mm) |
| wall thicknesses range | 0.002 to 0.015 in. (0.05 to 0.4 mm) |
|
Standards |
ASTM A908 |
| Specalized in | small diameter size |
| Finish | Polished Grit 120 - 600, Seamless, Welded, Brushed, Pickled, Solution Annealed and Pickled up to O.D. 219.1mm,Mirror Polished |
SS Needle Tube Supplier, Stainless Steel Seamless Needle Tubing, High Quality SS Needle Tube, 304 Needle Steel Tubes, SS Needle Tube Manufacturer in India
Tubetec Piping Solutions is a Reputed Stainless Steel Needle Tube Manufacturer and Supplier in India. SS Needle Tube avaliable in various schedules, each suited for different applications: While SCH 5 and SCH 10 SS Needle Tube with thin wall thickness is used for accurate applications like hypodermic needles, the SCH 40 and SCH 80 SS Needle Tube for high pressure applications such as drug delivery systems, surgical tools, which require high strength and zero failure rates. We are also leading Stainless Steel Heat Exchanger Tube Manufacturer in India.
Grades of Stainless Steel Needle Tube
Stainless Steel Needle Tube Schedule Chart
| NB SIZES | SCH 5 | SCH 10 | SCH 40 | SCH 80 | SCH 160 |
|
1/8″
|
|
|
|
|
|
|
1/4″
|
|
|
|
|
|
|
3/8″
|
|
|
|
|
|
|
1/2″
|
|
|
|
|
|
|
3/4″
|
|
|
|
|
|
|
1″
|
|
|
|
|
|
|
1 1/4″
|
|
|
|
|
|
|
1 1/2″
|
|
|
|
|
|
|
2″
|
|
|
|
|
|
|
2 1/2″
|
|
|
|
|
|
|
3″
|
|
|
|
|
|
|
4″
|
|
|
|
|
|
|
5″
|
|
|
|
|
|
|
6″
|
|
|
|
|
Stainless Steel Needle Tube Pressure Rating
| AVE. WALL INCHES | MIN YIELD STRENGTH (PSI) | MIN TENSILE STRENGTH (PSI) | THEORETICAL BURST PRESSURE * (PSI) | WORKING PRESSURE (PSI) 25% OF BURST | THEORETICAL YIELD POINT ** (PSI) | COLLAPSE PRESSURE *** (PSI) | |
| 0.250 | 0.020 | 30,000 | 75,000 | 14,286 | 3,571 | 5,714 | 4,416 |
| 0.250 | 0.028 | 30,000 | 75,000 | 21,649 | 5,412 | 8,660 | 5,967 |
| 0.250 | 0.035 | 30,000 | 75,000 | 29,167 | 7,292 | 11,667 | 7,224 |
| 0.250 | 0.049 | 30,000 | 75,000 | 48,355 | 12,089 | 19,342 | 9,455 |
| 0.250 | 0.065 | 30,000 | 75,000 | 81,250 | 20,313 | 32,500 | 11,544 |
| 0.375 | 0.020 | 30,000 | 75,000 | 8,955 | 2,239 | 3,582 | 3,029 |
| 0.375 | 0.028 | 30,000 | 75,000 | 13,166 | 3,292 | 5,266 | 4,145 |
| 0.375 | 0.035 | 30,000 | 75,000 | 17,213 | 4,303 | 6,885 | 5,077 |
| 0.375 | 0.049 | 30,000 | 75,000 | 26,534 | 6,634 | 10,614 | 6,816 |
| 0.375 | 0.065 | 30,000 | 75,000 | 39,796 | 9,949 | 15,918 | 8,597 |
| 0.500 | 0.020 | 30,000 | 75,000 | 6,522 | 1,630 | 2,609 | 2,304 |
| 0.500 | 0.028 | 30,000 | 75,000 | 9,459 | 2,365 | 3,784 | 3,172 |
| 0.500 | 0.035 | 30,000 | 75,000 | 12,209 | 3,052 | 4,884 | 3,906 |
| 0.500 | 0.049 | 30,000 | 75,000 | 18,284 | 4,571 | 7,313 | 5,304 |
| 0.500 | 0.065 | 30,000 | 75,000 | 26,351 | 6,588 | 10,541 | 6,786 |
| 0.500 | 0.083 | 30,000 | 75,000 | 37,275 | 9,319 | 14,910 | 8,307 |
| 0.625 | 0.020 | 30,000 | 75,000 | 5,128 | 1,282 | 2,051 | 1,859 |
| 0.625 | 0.028 | 30,000 | 75,000 | 7,381 | 1,845 | 2,953 | 2,568 |
| 0.625 | 0.035 | 30,000 | 75,000 | 9,459 | 2,365 | 3,784 | 3,172 |
| 0.625 | 0.049 | 30,000 | 75,000 | 13,947 | 3,487 | 5,579 | 4,335 |
| 0.625 | 0.065 | 30,000 | 75,000 | 19,697 | 4,924 | 7,879 | 5,591 |
| 0.625 | 0.083 | 30,000 | 75,000 | 27,124 | 6,781 | 10,850 | 6,910 |
| 0.625 | 0.095 | 30,000 | 75,000 | 32,759 | 8,190 | 13,103 | 7,734 |
| 0.625 | 0.109 | 30,000 | 75,000 | 40,172 | 10,043 | 16,069 | 8,639 |
| 0.750 | 0.028 | 30,000 | 75,000 | 6,052 | 1,513 | 2,421 | 2,156 |
| 0.750 | 0.035 | 30,000 | 75,000 | 7,721 | 1,930 | 3,088 | 2,669 |
| 0.750 | 0.049 | 30,000 | 75,000 | 11,273 | 2,818 | 4,509 | 3,664 |
| 0.750 | 0.065 | 30,000 | 75,000 | 15,726 | 3,931 | 6,290 | 4,749 |
| 0.750 | 0.083 | 30,000 | 75,000 | 21,318 | 5,330 | 8,527 | 5,905 |
| 0.750 | 0.095 | 30,000 | 75,000 | 25,446 | 6,362 | 10,179 | 6,637 |
| 0.750 | 0.109 | 30,000 | 75,000 | 30,733 | 7,683 | 12,293 | 7,453 |
| 0.750 | 0.120 | 30,000 | 75,000 | 35,294 | 8,824 | 14,118 | 8,064 |
| 0.875 | 0.020 | 30,000 | 75,000 | 3,593 | 898 | 1,437 | 1,340 |
| 0.875 | 0.028 | 30,000 | 75,000 | 5,128 | 1,282 | 2,051 | 1,859 |
| 0.875 | 0.035 | 30,000 | 75,000 | 6,522 | 1,630 | 2,609 | 2,304 |
| 0.049 | 30,000 | 75,000 | 9,459 | 2,365 | 3,784 | 3,172 | |
| 0.875 | 0.065 | 30,000 | 75,000 | 13,087 | 3,272 | 5,235 | 4,126 |
| 0.875 | 0.083 | 30,000 | 75,000 | 17,560 | 4,390 | 7,024 | 5,152 |
| 0.875 | 0.095 | 30,000 | 75,000 | 20,803 | 5,201 | 8,321 | 5,807 |
| 0.875 | 0.109 | 30,000 | 75,000 | 24,886 | 6,221 | 9,954 | 6,543 |
| 0.875 | 0.120 | 30,000 | 75,000 | 28,346 | 7,087 | 11,339 | 7,100 |
| 1.000 | 0.028 | 30,000 | 75,000 | 4,449 | 1,112 | 1,780 | 1,633 |
| 1.000 | 0.035 | 30,000 | 75,000 | 5,645 | 1,411 | 2,258 | 2,027 |
| 1.000 | 0.049 | 30,000 | 75,000 | 8,149 | 2,037 | 3,259 | 2,796 |
| 1.000 | 0.065 | 30,000 | 75,000 | 11,207 | 2,802 | 4,483 | 3,647 |
| 1.000 | 0.083 | 30,000 | 75,000 | 14,928 | 3,732 | 5,971 | 4,567 |
| 1.000 | 0.095 | 30,000 | 75,000 | 17,593 | 4,398 | 7,037 | 5,159 |
| 1.000 | 0.109 | 30,000 | 75,000 | 20,908 | 5,227 | 8,363 | 5,827 |
| 1.000 | 0.120 | 30,000 | 75,000 | 23,684 | 5,921 | 9,474 | 6,336 |
| 1.000 | 0.134 | 30,000 | 75,000 | 27,459 | 6,865 | 10,984 | 6,963 |
| 1.250 | 0.035 | 30,000 | 75,000 | 4,449 | 1,112 | 1,780 | 1,633 |
| 1.250 | 0.049 | 30,000 | 75,000 | 6,380 | 1,595 | 2,552 | 2,260 |
Stainless Steel Needle Tube Chemical Compositions
| Carbon | 0.08max |
| Manganese | 2.00max |
| Phosphorous | 0.040max |
| Sulfur | 0.030max |
| Silicon | 0.75max |
| Chromium | 18.0~20.0 |
| Nickel | 8.0~11.0 |
Stainless Steel Needle Tube Mechanical Properties
| Tensile strength, ksi(MPa) | 150-200 (1030-1370) |
Application of Stainless Steel Needle Tube
-
Energy industries
-
Chemicals
-
Modern Architecture
-
Textile Machinery
-
Construction
-
Oil & Gas Industry
-
Ship Building
-
Pulp and Paper
